Noctua NF-A14X25 G2 PWM Next-Gen 140mm Premium Fan

Chat Terlebih Dahulu Untuk Memastikan Ketersediaan Barang
https://www.tokopedia.com/pinpointcomputer/noctua-nf-a14x25-g2-pwm-next-gen-140mm-premium-fan-1730857820325905490
Garansi Resmi: FOXHOUND
Specifications:
Product Details
Notes and warnings Further reading:
NF-A14x25(r) G2 performance: improvements for heatsinks, radiators and cases
NF-A14x25(r) G2 aerodynamic design innovations: the keys to its superior performance
etaPERF™ motor: new standards in energy efficiency
SupraTorque™: leveraging torque headroom to boost pressure performance
Fan speed offset: Beat frequency theory and how to further optimise acoustics
FAN Specification
Size 140x140x25 mm
Mounting hole spacing 124.5×124.5 mm
Connector & pin-configuration 4-pin PWM
Cable length 20cm + 30cm NA-EC1 extension cable
Bearing SSO2
Blade geometry A-Series with Flow Acceleration Channels
Frame technology AAO (Advanced Acoustic Optimisation)
Material Sterrox® LCP
Rotational speed (+/- 10%) 1500 RPM
Rotational speed with L.N.A. (+/- 10%) 1250 RPM
Airflow 155.6 m³/h
Airflow with L.N.A. 127.1 m³/h
Acoustical noise 24.8 dB(A)
Acoustical noise with L.N.A. 19.7 dB(A)
Static pressure 2.56 mm H₂O
Static pressure with L.N.A. 1.3 mm H₂O
Input power (max.) 2.28 W
Max. input current 0.19 A
Operating voltage 12 V
MTTF > 150,000 h
Scope of delivery
NA-RC16 Low-Noise Adaptor (L.N.A.)
NA-YC1 4-pin PWM splitter cable
NA-EC1 30cm extension cable
4x NA-AV2 anti-vibration mounts
NA-AVG2-LR anti-vibration gasket
4x NA-AVP1-LR load-relief anti-vibration pads
Fan screws
Warranty 6 years
